Molded Trimming Pot 2

Alpha Products Inc - 351 Irving Drive, Oxnard, CA 93030, USA - Tel: 805-981-8666 - Fax: 805-988-6555 - Contact Us

Corporate Website

Send Your Specs

Other Catalogs

Contact Us

Std. Tapers

Part Number

Model number

Taper

Resistance value

3RP/M296P

B

Specify (100 Ohm ~ 1MOhm)

Select Part Numbers from the table then click on the Request a Quote Button to send your requirements for Price and Delivery. If you need custom product please use the Send your Specs Button

Circuit

Electrical Characterisics

Mechanical Characteristics

Resistance Values

100 Ohm ~ 1 MOhm +/-10%

Torque

3.0 oz/in max

Resistance Taper

B (linear)

Mechanical Stops

Wiper idles

Power Rating

0.75W @70C, 0W @125C

Vibration

20G

Absolute Minimum Resistance

2 Ohm max

Shock

100G

Contact Resistance Variation

3 Ohm max

Temperature

-55C to + 125C

Voltage Adjustability

+/- 0.01%

Rotational Life

200 cycles

Resistance Adjustability

+/- 0.05%





Resolution

Infinitive





Insulation Resistance

1000M Ohm min @500V DC





Adjustment Angle

28 turns nom.





Dielectric Strength

900V AC @sea level
