Molded Trimming Pot 11

Alpha Products Inc - 351 Irving Drive, Oxnard, CA 93030, USA - Tel: 805-981-8666 - Fax: 805-988-6555 - Contact Us

Corporate Website

Send Your Specs

Other Catalogs

Contact Us

Std. Tapers

Part Number

Model number


Resistance value



Specify (100 Ohm ~ 1MOhm)

Select Part Numbers from the table then click on the Request a Quote Button to send your requirements for Price and Delivery. If you need custom product please use the Send your Specs Button


Electrical Characterisics

Mechanical Characteristics

Resistance Values

100 Ohm ~ 1 MOhm +/-10%


30 ~ 200 gf/cm

Resistance Taper

B (linear)

Shaft Stopper Strength

1 Kgf/cm

Power Rating

0.75W @70C, 0W @125C


-55C to + 125C

Operating voltage

250V AC


200 cycles

Residual Resistance

1% max



Rotational Noise

150mV max



Withstanding Voltage

600V AC for 1 minute



Insulation Resistance

100M Ohm min @500V DC
