Standard Slide Potentiometer 2

Alpha Products Inc - 351 Irving Drive, Oxnard, CA 93030, USA - Tel: 805-981-8666 - Fax: 805-988-6555 - Contact Us

Corporate Website

Send Your Specs

Other Catalogs

Contact Us

Std. Tapers

Request for Quote

Part Number

Model number

Lever code

Style

Taper

Value in Ohms

3SP/C1001G

1

A1

Select Part Numbers from the table then click on the “Request a Quote” Button to send your requirements for Price and Delivery. If you need custom product please use the “Send your Specs” Button

Circuit

Electrical Characterisics

Mechanical Characteristics

Resistance Values

500 Ohm ~ 1MOhm  +/- 20%

Push / Pull Strength

2.5 kgf/cm

Resistance Taper

A, B, C

Stop Strength

2.5 kgf/cm

Residual Resistance

0.1% max of total resistance

Operating Force

20 ~ 200 gf

Rated Power

taper A, C = 0.01W
taper B = 0.015W

LIfe

15,000 cycles

Operating Voltage

taper A, C = 50V AC
taper B = 100V AC

Insulation Resistance

50MOhm min @100V DC

Withstand Voltage

250V AC for 1 minute

Type Of Lever

CODE

1

DIM “L”

10.0

Disclaimer: Alpha Products, Inc. makes no warranties, expressed or implied, including warranties of merchant ability or fitness /suitability for a particular purpose or application. Under no circumstances shall Alpha Products, Inc. be liable for incidental, consequential, or other damages from alleged negligence, breach of warranty, strict liability, tort, contract, or any other theory, arising out of the use, non use, or handling of these products.
Alpha Products Inc. reserves the right to discontinue, modify, amend and / or change any product, specification or service at any time without any obligation of providing any notice.
