Chip Trimmer Pot 3

Alpha Products Inc - 351 Irving Drive, Oxnard, CA 93030, USA - Tel: 805-981-8666 - Fax: 805-988-6555 - Contact Us

Corporate Website

Send Your Specs

Other Catalogs

Contact Us

Std. Tapers

Part Number

Model number

Style

Taper

Value in Ohms

3TP/1501N

A1

Select Part Numbers from the table then click on the Request a Quote Button to send your requirements for Price and Delivery. If you need custom product please use the Send your Specs Button

Circuit

Electrical Characterisics

Mechanical Characteristics

Total Resistance

100 Ohm ~ 2MOhm +/- 20%

Total Rotational Angle

270 deg +/- 20 deg

Power Rating

0.1W

Rotational Torque

20 ~ 200 gf/cm

Operating Voltage

100V max

Rotational Stop Strength

7 kgf/cm

Resistance Taper

B

Life

10,000 cycles

Residual Resistance

0.1% max

Slide Noise

100mV max
