16mm Rotary Encoder 2

Alpha Products Inc - 351 Irving Drive, Oxnard, CA 93030, USA - Tel: 805-981-8666 - Fax: 805-988-6555 - Contact Us

Corporate Website

Send Your Specs

Other Catalogs

Contact Us

Std. Tapers

Part Number

Model number

Bushing

Shaft

Style

Clicks

3EN/161

E

D1

Select Part Numbers from the table then click on the Request a Quote Button to send your requirements for Price and Delivery. If you need custom product please use the Send your Specs Button

Electrical Characterisics

Mechanical Characteristics

Rating

0.5mA @ 5V DC

Total Rotational Angle

360 deg

Withstanding Voltage

50V AC

Push / pull Strength

7 kgf

Insulation Resistance

10MOhm min @50V DC

Click Position

12, 24

Click Torque

40 ~ 204 gf/cm

Life

100,000 cycles

Type Of Shaft

CODE

2

3

4

DIM L

15.0

20.0

25.0

DIM T

7.0

12.0

12.0

CODE

A

B

C

DIM L

15.0

20.0

25.0

DIM F

7.0

12.0

12.0

Length of bushing

CODE

1

2

DIM N

5.0

7.0
